TYVcure UVMH
TYVcure UVMH

TYVcure UVMH is developed for UV-cured pipe rehabilitation processes, specifically for inversion lining repairs. It can be used as a matrix material for in-situ or pre-impregnated composites.


Composition

TYVcure UVMH is a methacrylate-based, one-component system that includes the necessary UV initiator and is completely Styrene-free.

  • Methacrylate-based blend with UV initiator One-component system, Styrene-free

Properties

  • excellent chemical resistance
  • high mechanical properties
  • good adhesion on concrete and steel

Technical data

Liquid component technical data

NameValueUnit
density1.1 ± 0.1g/cm3
viscosity3000 ± 400mPas
flash point>100°C
appearance, colortransparent, yellowish liquid

Hardened resin technical data

NameValueUnit
Young’s modulus> 3200MPa
Tensile strength> 60MPa
Elongation at break> 2.5%
Flexural modulus> 3000MPa
Flexural strength> 110MPa
Compressive strength> 150MPa
Shore-D hardness> 80Shore-D
Glass-transition temperature120 ± 15°C

Chemical resistance

To assess chemical resistance, we introduced a rating system from 1 to 5, with 5 indicating the highest resistance.

ChemicalResult
Normal petrol5
Super petrol5
CaCl2- saturated5
Diesel5
Acetic acid 10%5
Acetic acid 20%5
Ethanol3
Oil5
Phosphoric acid 10%5
H2O2 30%4
H2O2 5%5
H2SO4 10%5
H2SO4 20%5
H2SO4 40%5
HCl 10%5
HCl 37%5
HNO3 10%5
HNO3 20%5
HNO3 40%3
IPA5
MgCl2- saturated5
NaCl 20%5
NaOH 10%5
NaOH 30%5
NaOH 50%5
Lactic acid 10%5
Toloul5
