TYVcure EPL60

Epoxy Resins
TYVcure EPL60
TYVcure EPL60

TYVcure EPL60 is a two-component epoxy coating system developed for repairing and renovating drains and sewage pipes. The system is suited for the impregnation of liners/hoses and can be cured at both ambient and high temperatures, designed specifically for medium length sections.


Composition

TYVcure EPL60 resin consists of two liquid components:

  • A component: epoxy containing blend
  • B component: amine containing blend with special odor

Properties

  • hot cure either warm air or steam
  • good mechanical properties
  • good chemical resistance
  • adheres to PVC, concrete, steel

Technical data

Liquid component technical data

NameValueUnit
density of 'A' component1.2 ± 0.1g/cm3
viscosity of 'A' component5500 ± 500mPas
density of 'B' component1.0 ± 0.1g/cm3
viscosity of 'B' component250 ± 50mPas
density of mixture1.1 ± 0.1g/cm3
viscosity of mixture2600 ± 400mPas

Hardened resin technical data

NameValueUnit
Young’s modulus> 2800MPa
Tensile strength> 45MPa
Elongation at break> 1.5%
Flexural modulus> 2800MPa
Flexural strength> 90MPa
Compression strength> 130MPa
Shore-D hardness> 80Shore-D
Glass-transition temperature> 90°C

Chemical resistance

To assess chemical resistance, we introduced a rating system from 1 to 5, with 5 indicating the highest resistance.

ChemicalResult
Normal petrol5
Super petrol5
CaCl2- saturated5
Diesel5
Acetic acid 10%5
Acetic acid 20%1
Ethanol5
Oil5
Phosphoric acid 10%1
H2O2 30%1
H2O2 5%4
H2SO4 10%4
H2SO4 20%3
H2SO4 40%5
HCl 10%5
HCl 37%1
HNO3 10%5
HNO3 20%2
HNO3 40%5
IPA5
MgCl2- saturated5
NaCl 20%5
NaOH 10%5
NaOH 30%5
NaOH 50%5
Lactic acid 10%5
Toluol5
